二工位油浸式负荷开关
Two-position loadbreak switches
-
TYN33-2/630
产品应用：
油浸式负荷开关安装在组合变压器内部，以变压器油作为绝缘及灭弧介质的三相联动负荷开关。操作为弹簧机构。该负荷开关分二工位、四工位两种，分别用于终端美式箱变及环网美式箱变。安装方式可以为侧面安装和顶部安装。此开关适用于地埋式变压器。使用前要随变压器干燥处理。
Loadbreak switches lnstalled in the combination of transformer internal, transformer oil as insulation and arc medium three-phase linkage load switch. operation for spring mechanism. the load switch is divided into two units, four units of two, respectively, for the terminal american box and the united states box change box. the installation can be for side mounting and top mounting. This switch is suitable for buried transformers. before use with the transformer drying。
油浸式负荷开关安装在组合变压器内部，以变压器油作为绝缘及灭弧介质的三相联动负荷开关。操作为弹簧机构。该负荷开关分二工位、四工位两种，分别用于终端美式箱变及环网美式箱变。安装方式可以为侧面安装和顶部安装。此开关适用于地埋式变压器。使用前要随变压器干燥处理。
Loadbreak switches lnstalled in the combination of transformer internal, transformer oil as insulation and arc medium three-phase linkage load switch. operation for spring mechanism. the load switch is divided into two units, four units of two, respectively, for the terminal american box and the united states box change box. the installation can be for side mounting and top mounting. This switch is suitable for buried transformers. before use with the transformer drying。
